Power：50W
Series：CC LED Driver
Application：High Pole light, High bay light, Stadium light, Horticulture light, Fish light, Street light, Tunnel light, Stage light
Certificate：ENEC, EAC, UKCA, CCC, CE
Warranty：5 years
Efficiency up to 89%
Output current adjustment method: Dimmer line programming
Isolated dimming: 0-10V, PWM, Resistor
TIM，ELA，CLO
Suitable for Class I /II lamps
Protections: SCP/OTP/OVP/OPP
Surge protection: CM: 10kV, DM: 6kV
IP66/IP67
| Reted Input Voltage | 100~305Vac |
| Input Frequency Range | 50/60Hz |
| Max. Pout | 50W |
| Dimension | 105*66*31.5（mm） |
| Model | AC Input Range（Vac） | Max. Pout（W） | Vout Range（Vdc） | Full Power Vout Range（Vdc） | Iout（A） | THD(Typ.) | PF(Typ.) | Eff.(Typ.) | Max.Tc |
| SS-50GA-E62* | 100-305 | 50 | 30-62 | 38-62 | 0.1-1.3 | 8% | 0.97 | 88% | 90℃ |
| SS-50GA-E100* | 100-305 | 50 | 50-100 | 62-100 | 0.1-0.8 | 8% | 0.97 | 88.5% | 90℃ |
| Carton Dimension | L×W×H =495×385×162 (mm) |
